Series A 105 Blind Flange ASME B16.47 Forged 40IN
Key Specifications / Features
Model No.: DB-PIPE FLANGE-867 Hits: 25
China Series A 105 Blind Flange Factory Derbo Offers Series A 105 Blind Flange, ASME B16.47, Forged, 40IN, 150LB, Black Painting, Pipe Connection.
Request a quote
Share
Tags:
Detail Information
Type: Blind Flange.
Material and Grade: SA105.
Standard: ASME B16.47.
Size: 40IN, 150#.
Manufacture Method: Forged.
Surface Treatment: Usually Black Painting/Oiled/Galvanized, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Wooden Case or As Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Material and Grade: SA105.
Standard: ASME B16.47.
Size: 40IN, 150#.
Manufacture Method: Forged.
Surface Treatment: Usually Black Painting/Oiled/Galvanized, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Wooden Case or As Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
| Chemical Composition and Mechanical Property for ASTM A105 | |||||||||
| Grade | Chemical Composition | Mechanical Performance | |||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Cu(Max) | Ni(Max) | Tensile Strength(Min) | Yield Strength(Min) | |
| Mpa | Mpa | ||||||||
| A105 | 0.35 | 0.6-1.05 | 0.035 | 0.04 | 0.1-0.35 | 0.4 | 0.4 | 485 | 250 |
