ASTM A420 Slip On Flange Forged DN200 PN20 Raised Face
Key Specifications / Features
Model No.: DB-Carbon Steel Flange-786 Hits: 91
China ASTM A420 Slip On Flange Factory Derbo Supplies ASTM A420 Slip On Flange, Forged, DN200, PN20, Raised Face, Oiled, Carbon Steel, Pipe Connection.
Request a quote
Share
Tags
Detail Information
Type: Slip On Flange.
Material and Grade: ASTM A420.
Size: DN200, PN20.
Connection Face: RF.
Manufacture Method: Forged.
Surface Treatment: Painting/Oiled/Coating/Sand Blast.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Pallet/Wooden Case or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Material and Grade: ASTM A420.
Size: DN200, PN20.
Connection Face: RF.
Manufacture Method: Forged.
Surface Treatment: Painting/Oiled/Coating/Sand Blast.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Pallet/Wooden Case or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
| Chemical Composition and Mechanical Property for ASTM A420 | |||||||||
| Grade | Chemical Composition | Mechanical Performance | |||||||
| WPL6 | C | Si | Mn | P(Max) | S(Max) | Cr | Mo | Tensile Strength | Yield Strength |
| (Min) | |||||||||
| 0.3 | 0.15-0.40 | 0.5-1.35 | 0.035 | 0.04 | 0.3 | 0.12 | Mpa | Mpa | |
| 415-655 | 240 | ||||||||
