ASTM A321 316 Stainless Steel Pipe Cold Drawn 4 Inch 20S Polished
Key Specifications / Features
Model No.: DB-Stainless Steel Pipe-681 Hits: 231
China ASTM A321 316 Stainless Steel Pipe Manufacturer Derbo Offers ASTM A321 316 Stainless Steel Pipe, Cold Drawn, 4 Inch, SCH 20S, Polished Surface.
Request a quote
Share
Tags
Detail Information
Type: Stainless Steel Pipe.
Material and Grade: ASTM A321 316.
Size: 4 Inch, 20S.
Manufacture Method: Cold Drawn.
Surface Treatment: Polished, Pickling, Annealed.
Independence Inspection: Chemical Test, Mechanical Test.
Application: Used for Fluid and Gas Transportation, Boiler and Machining, etc.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: in Bundles or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Material and Grade: ASTM A321 316.
Size: 4 Inch, 20S.
Manufacture Method: Cold Drawn.
Surface Treatment: Polished, Pickling, Annealed.
Independence Inspection: Chemical Test, Mechanical Test.
Application: Used for Fluid and Gas Transportation, Boiler and Machining, etc.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: in Bundles or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Steel Grade |
Chemical Composition (%) | |||||||
| C | Mn | P | S | Si | Cr | Ni | Mo | |
| TP316 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 |
| TP316L | 0.035 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 |
| TP316H | 0.04-0.10 | 2 | 0.045 | 0.03 | 0.75 | 16.0-18.0 | 11.0-14.0 | 2.00-3.00 |
Steel Grade |
Mechanical Properties | ||
| （Mpa） Tensile Strength |
(Mpa) Yield Strength |
（%） Elongation |
|
| TP316 | ≥515 | ≥205 | ≥35 |
| TP316L | ≥485 | ≥170 | ≥35 |
| TP316H | ≥515 | ≥205 | ≥35 |
