ASTM A234 Gr.WPB Carbon Steel Cap ASME B16.9 Wrought 1/4 Inch
Key Specifications / Features
Model No.: DB-Carbon Steel Pipe Fittings-827 Hits: 331
China ASTM A234 Gr.WPB Carbon Steel Cap Factory Derbo Supplies ASTM A234 Gr.WPB Carbon Steel Cap, ASME B16.9, Wrought, 1/4 Inch, SCH 20, SMLS, Coating.
Request a quote
Share
Tags
Detail Information
Type: Carbon Steel Cap.
Material and Grade: ASTM A234, Gr.WPB.
Standard: ASME B16.9.
Connection Way: BW.
Size: 1/4 Inch, SCH 20.
Manufacture Method: Wrought.
Surface Treatment: Usually Black Painting, Coating, Galvanized, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Pallet/Wooden Case or As Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Material and Grade: ASTM A234, Gr.WPB.
Standard: ASME B16.9.
Connection Way: BW.
Size: 1/4 Inch, SCH 20.
Manufacture Method: Wrought.
Surface Treatment: Usually Black Painting, Coating, Galvanized, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Pallet/Wooden Case or As Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
| Chemical Composition and Mechanical Property for ASTM A234 | |||||||||||
Grade |
Chemcial Composition | Mechanical Performance | |||||||||
| C(Max) | Mn | P(Max) | S(Max) | Si(Min) | Cr(Max) | Mo(Max) | Ni(Max) | Cu(Max) | Tensile Strength (Min) |
Yield Strength (Min) |
|
| Mpa | Mpa | ||||||||||
| WPB | 0.3 | 0.29-1.06 | 0.05 | 0.058 | 0.1 | 0.4 | 0.15 | 0.4 | 0.4 | 415-585 | 240 |
