ASTM A216 2PC Ball Valve, 12 Inch, CL600, API 6D
Key Specifications / Features
Model No.: DB-Valve-57 Hits: 185
China ASTM A216 2PC Ball Valve Manufacturer Derbo offers ASTM A216 WCB 2PC Ball Valve, 12 Inch, Class 600, API 6D, API 607, ANSI B16.34, Threaded Ends.
Request a quote
Share
Tags
Detail Information
Name: 2PC Ball Valve.
Type: Trunnion Mounted.
Body / Bonnet Material: ASTM A216 WCB.
Trim: 1#.
Size: 12 Inch.
Pressure class: Class 600.
Connection: Threaded Ends.
Operator: Worm Actuator.
Body / Bonnet Structure: BB OS & Y.
Standard: API 6D, API 607.
Design Standard: ANSI B16.34.
Type: Trunnion Mounted.
Body / Bonnet Material: ASTM A216 WCB.
Trim: 1#.
Size: 12 Inch.
Pressure class: Class 600.
Connection: Threaded Ends.
Operator: Worm Actuator.
Body / Bonnet Structure: BB OS & Y.
Standard: API 6D, API 607.
Design Standard: ANSI B16.34.
| Chemical Composition and Mechanical Property For ASTM A216 | |||||||||||||||
| Steel Grade | Chemical Composition | Mechanical performance | |||||||||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Ni(Max) | Cr(Max) | Mo(Max) | Cu(Max) | V(Max) | Tensile Strength (Min） |
Yield Strength (Min) |
Elongation (Min) |
|||
| (Min) | |||||||||||||||
| ksi | Mpa | ksi | Mpa | % | |||||||||||
| WCB | 0.3 | 1 | 0.04 | 0.045 | 0.6 | 0.5 | 0.5 | 0.2 | 0.3 | 0.03 | 70-95 | 485-655 | 36 | 250 | 22 |
