ASTM A106 Gr.B Galvanized Pipe, 3 Inch, SCH 40, 6M, BE
Key Specifications / Features
Model No.: DB-GI-CS-SMLS-100 Hits: 369
China ASTM A106 Gr.B Galvanized Seamless Pipe Manufacturer Derbo offers ASTM A106 Gr.B Galvanized Pipe, OD 3 Inch, SCH 40, 6 Meters, BE Ends.
Request a quote
Share
Tags
Detail Information
Type: Galvanized Seamless Pipe.
Material: ASTM A106 Gr.B.
OD: 3 Inch.
W.T: SCH.40.
Length: 6M.
Standard: ASTM A153.
Ends: BE.
Surface Treatment: Galvanized.
Material: ASTM A106 Gr.B.
OD: 3 Inch.
W.T: SCH.40.
Length: 6M.
Standard: ASTM A153.
Ends: BE.
Surface Treatment: Galvanized.
| ASTM A106 CHEMICAL COMPOSITION (%) | ||||||||||
| Steel Grade | C max |
Si max |
Mn max |
P max |
S max |
Ni Max |
Cr max |
Cu max |
Mo max |
V max |
| B | 0.30 | 0.10 | 0.29-1.06 | 0.035 | 0.035 | 0.40 | 0.40 | 0.40 | 0.15 | 0.08 |
| ASTM A106 MECHANICAL PROPERTIES | |||
| Steel Grade | Yield Strength Min (Mpa) |
Tensile Strength Min (Mpa) |
Elongation Min (%) |
| B | 240 | 415 | AS PER ASME SA106/ASTM A106 |
