ASTM A105 Weldolet, MSS-SP-97, 3×20 Inch, SCH 80, BW Ends
Key Specifications / Features
Model No.: DB-Olet-55 Hits: 1830
China ASTM A105 Weldolet Manufacturer Derbo offers ASTM A105 Weldolet, 3×20 Inch, Wall Thickness SCH 80, Standard MSS-SP-97, Butt Weld Ends.
Request a quote
Share
Tags
Detail Information
Type: Weldolet.
Material: ASTM A105.
Size: 3×20 Inch.
W.T.: SCH 80.
Standard: MSS-SP-97.
Ends: Butt Weld Ends.
Material: ASTM A105.
Size: 3×20 Inch.
W.T.: SCH 80.
Standard: MSS-SP-97.
Ends: Butt Weld Ends.
| Chemical Composition and Mechanical Property For ASTM A105 | |||||||||||||||
| Steel Grade | Chemical Composition | Hardness | Mechanical performance | ||||||||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Cu(Max) | Ni(Max) | Cr(Max) | Mo(Max) | V(Max) | HB, max | Tensile strength (Min） |
Yield Strength (Min) |
|||
| psi | Mpa | psi | Mpa | ||||||||||||
| A105 | 0.35 | 0.6-1.05 | 0.035 | 0.04 | 0.1-0.35 | 0.4 | 0.4 | 0.3 | 0.12 | 0.12 | 187 | 70000 | 485 | 36000 | 250 |
