A182 Lever Operated Ball Valve, 2 Inch, 1000LB, BS 1868
Key Specifications / Features
Model No.: DB-SS-VALVE-123 Hits: 65
China ASTM A182 F316 Ball Valve Manufacturer Derbo offers A182 F316 Lever Operated Ball Valve, 2 Inch, 1000LB, BS 1868, API 608, BB OS&Y, Threaded Ends.
Request a quote
Share
Tags
Detail Information
Type: Lever Operated Ball Valve.
Material: ASTM A182 F316.
Size: 2 Inch.
Pressure class: 1000LB.
Connection: Threaded Ends.
Body / Bonnet Structure: BB OS&Y.
Standard: API 608, BS 1868.
Design Standard: ANSI B16.34.
Test Standard：API598.
Material: ASTM A182 F316.
Size: 2 Inch.
Pressure class: 1000LB.
Connection: Threaded Ends.
Body / Bonnet Structure: BB OS&Y.
Standard: API 608, BS 1868.
Design Standard: ANSI B16.34.
Test Standard：API598.
| Chemical Composition and Mechanical Property For ASTM A182 | ||||||||||
| Steel Grade | Chemical Composition | Mechanical performance | ||||||||
| C(Max) | Mn(Max) | P(Max) | S(Max) | Si(Max) | Cr | Ni | Mo | Tensile Strength | Yield Strength | |
| F316 | 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 495 | 175 |
