A182 Gr.F11 CL2 Alloy WN Flange ASME B16.5 Forged 3 Inch 600#
Key Specifications / Features
Model No.: DB-Alloy WN Flange-527 Hits: 231
China A182 Gr.F11 CL2 Alloy WN Flange Manufacturer Derbo Offers A182 Gr.F11 CL2 Alloy WN Flange, ASME B16.5, Forged, 3 Inch, 600#, Oiled, Painting.
Request a quote
Share
Tags
Detail Information
Type: Alloy WN Flange.
Manufacture Method: Forged.
Standard and Material: A182 Gr.F11 CL2.
Size: 3 Inch, 600#.
Surface Treatment: Oiled/Painting.
Independence Inspection: Chemical Test, Mechanical Test.
Third Party Inspection: SGS, BV, INTERNET etc.
Application: Pipe Connection.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Manufacture Method: Forged.
Standard and Material: A182 Gr.F11 CL2.
Size: 3 Inch, 600#.
Surface Treatment: Oiled/Painting.
Independence Inspection: Chemical Test, Mechanical Test.
Third Party Inspection: SGS, BV, INTERNET etc.
Application: Pipe Connection.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
| Chemical Composition and Mechanical Property for ASTM A182 | |||||||||
| Steel Grade | Chemical Composition | Mechanical Performance | |||||||
| C | Si | Mn | P(Max) | S(Max) | Cr | Mo | Tensile Strength | Yield Strength (Min) |
|
| Mpa | Mpa | ||||||||
| F11 CL1 | 0.05-0.15 | 0.5-1.0 | 0.3-0.6 | 0.03 | 0.03 | 1.0-1.5 | 0.44-0.65 | 415 | 205 |
| F11 CL2 | 0.10-0.20 | 0.5-1.0 | 0.3-0.8 | 0.04 | 0.04 | 1.0-1.5 | 0.44-0.65 | 485 | 275 |
| F11 CL3 | 0.10-0.20 | 0.5-1.0 | 0.3-0.8 | 0.04 | 0.04 | 1.0-1.5 | 0.44-0.65 | 515 | 310 |
| F12 CL1 | 0.05-0.15 | ≤0.5 | 0.3-0.6 | 0.045 | 0.045 | 0.8-1.25 | 0.44-0.65 | 415 | 220 |
| F12 CL2 | 0.10-0.20 | 0.10-0.60 | 0.3-0.8 | 0.04 | 0.04 | 0.8-1.25 | 0.44-0.65 | 485 | 275 |
| F21 | 0.05-0.15 | ≤0.5 | 0.3-0.6 | 0.04 | 0.04 | 2.7-3.3 | 0.8-1.06 | 515 | 310 |
