A105N Welding Neck Flange Forged SCH 160 1500 LB RTJ
Key Specifications / Features
Model No.: DB-Flange-774 Hits: 338
China A105N Welding Neck Flange Factory Derbo Supplies A105N Welding Neck Flange, Forged, SCH 160, 1500 LB, RTJ Face, Painting, for Pipe Connection.
Request a quote
Share
Tags
Detail Information
Type: RTJ WN Flange.
Material and Grade: A105N.
Size: 1500 LB, SCH 160.
Manufacture Method: Forged.
Surface Treatment: Painting/Oiled/Sand Blast.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Packing: Pallet/Wooden Case or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
Material and Grade: A105N.
Size: 1500 LB, SCH 160.
Manufacture Method: Forged.
Surface Treatment: Painting/Oiled/Sand Blast.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Packing: Pallet/Wooden Case or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.
| Chemical Composition and Mechanical Property for ASTM A105 | |||||||||
| Grade | Chemical Composition | Mechanical Performance | |||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Cu(Max) | Ni(Max) | Tensile Strength(Min) | Yield Strength(Min) | |
| Mpa | Mpa | ||||||||
| A105 | 0.35 | 0.6-1.05 | 0.035 | 0.04 | 0.1-0.35 | 0.4 | 0.4 | 485 | 250 |
